item no.:
YX28-200-800/920lead time:
7-15daysproduct orgin:
Chinashipping port:
Xiamen/Qingdao/Tianjin,Chinapayment:
T/T；L/C at sightcolor:
Customized
What are corrugated sheets used for?
Corrugated metal galvanized roofing sheets,actually it is colorful steel pre-painted sheet,which is rolled and cold bended into different profiled boards.
A wide range of our company's commercial products and design options will allow you and your team to meet or surpass design objectives and building codes and standards for architect-designed buildings including:
schools, hospitals, apartment complexes, hotels, government buildings, offices, civic centers, stadiums, arenas, museums, churches, shopping complexes, transit facilities, warehouses and more.
Characters of Color Coated Steel Roof Tile Sheet :
☆1. light in weight, compare to the brick wall, light weight makes it more easy to handle, also save the space.
☆2.High strength, bending and compression resistance, used as building enclosure and bearing structure.
☆3. Easy to install, no need special tools, do not break, crack or leak.
☆4. Energy-saving, saving of the structural steel by up to 40%.
☆5. Ral color standard make your roof more beautiful, colorful.
☆6. Quake-proof, fire-proof, rain-proof, long life, maintenance-free.
☆7. We will provide the best solutions if you don't have a exact idea of the specification you want for the steel sheet based on your weather conditions, engineering structure, construction budget and so on.
Specification :
Model No.:
YX 28-200--800
YX 28-200-920
Rib height(mm):
28
28
Rib distance(mm)
200
200
Modular width(mm)
800
920
Feeding width(mm)
1000
1200
Available thickness(mm)
0.5
0.6
0.8
Section inertia(cm4/m)
10.28
12.05
16.34
Section resistance(cm3/m)
5.24
6.33
8.37
Available length:
20FT container: ≤5.95m
40FT container:≤11.95m
Available material:
PPGI/PPGL/Aluminum sheets/Al-mg-mn alloy metal sheets
Image Gallery：
Other roofing sheets:
|
YX15-225-900 |
YX35-125-750 |
|
YX20-114.5-1035 |
YX38-200-1000 |
|
YX25-205-820&1025 |
YX28-207-828 |
Free to contact us if you also have any interests on these sheets.
How do We Provide Better Service?
We focus on every detail of our products, including raw material quality control, production, package, loading, shipment and the final installation.
We are one combination of industry and trade company, and very professional with steel structure products in China.
Because of good quality and service, competitive price, our products are sold worldwide, such as America, South America, Europe, Southeast Asia, Africa etc.
1)Professional sales team,One-to-one service;
2)Combination of industry and trade company,to ensure the service and price;
3)Experienced engineer team to offer professional technology service;
4)Intimate after-sales service.
Experienced technology support, competitive price, professional service, we are here to help you go on with your project smoothly.
Packing & Delivery details:
☆ Packing：
Seaworthy packing standards：
1）Normal packing：
Packed with moisture-proof kraft paper.
2）Premium packing：
Packed with steel box.
☆ Delivery :
Delivery time for regular colors,coating types and thickness:7-10 days.
Delivery time for special colors,coating types and thickness:15-25 days.
Delivery terms:FOB/CIF/CFR/DDP is available.
We can find good forwarder for customer or accept appointed forwarder from customers.
Free to Contact us If You Have Any Interests on Roofing Steel Sheets.
This metal roofing sheets is classic and vintage type,whether the roofing is historic, contemporary, or ancient,this sheet metal and roofing can offer distinction to highlight buildings and provide memorable charm. MOQ:500m²/color & size
This color corrugated steel sheet (YX41-210-420) is designed as a kind of standing seam roofing cladding, it is widely used in industrial, commercial and large-scale buildings and so on.MOQ:500m²/color & size
This metal roofing is recommended for large span buildings.The roof panel need to be locked by machine or hand,after clip locked,the standing seam roof system could be completely impervious and waterproof. MOQ:500M² / Color&Size
This aluminum roofing sheet is a highly cost-effective roofing material, and with performance of corrosion resistant, waterproof, light weight, high strength and easy install, etc. MOQ:500M² / Color&Size
This kind of roof color steel plate is a concealed joint panel, it won’t be seen the nails on the steel sheet surface.MOQ:500m²/color & size
Standing seam roof panel is ideal for industrial, commercial and architectural applications. MOQ:500 M²/ Color & Size
