Floor Steel Decking sheet (also called corrugated galvanized steel sheet) is a cold formed corrugated steel sheet supported by beams.
The steel decking acts as a permanent form work to the concrete during construction and then acts compositely with the concrete to produce a strong and stiff long span floor. Temporary propping is not required in most applications.After molding, can be divided into closed type, open type and necking type.
Product Advantages:
☆Light weight, high strength, good bearing performance, good anti-seismic performance;
☆ Easy and quick construction, simple assembled;
☆ To replace the traditional templates and improve shortcomings of traditional templates;
☆As part of the structural strength, to reduce the materials cost;
☆Easy reinforcement, wiring, piping construction;
☆Neat and nice looking.
Decking Sheets Specification:
Model No.
|
YX75-230-690
|
Rib height
|
75mm
|
Rib distance
|
230mm
|
Modular width
|
690mm
|
Feeding width
|
1000mm
|
Material
|
Galvanized /Galvalume steel
|
Thickness
|
0.75~1.5mm
|
Steel material
|
High strength galvanized steel sheets
|
Material standards
|
Q234,Q345,Q355,G550
|
Zinc coating
|
120~275g/㎡
|
Length
|
Max 5.95 meters for 20ft container;
|
Max 11.95 meters for 40ft container.
|
Model Base:
Design Considerations:
- These are following design considerations that we put to manufacture these sheets:
- Adhesion, fixing or ballasting are notable design factors for long lasting capability
- Materials chosen are fire proof
- Well designed to bear extra loads
- Condensation risk is also the designing factor
- Designed to provide better insulation
- Able to fulfill the acoustic requirements
- Whole design is compact and light in weight
- Designed meticulously in conjugation with the aesthetic importance
Applications:
Chemical plants, cement industry, high storey buildings, office buildings, multiplexes and so on.
Packing & Delivery:
☆Packing:
Seaworthy packing standards:
Packed with moisture-proof kraft paper.
☆Delivery:
Delivery time for small order with stock material :7-10 days;
Delivery time for special requirement,coating types and thickness:15-25 days;
Delivery tems:FOB/CIF/CFR/DDP is available;
We can find good forwarder for customers or accept appointed forwarder from customers.
Please don't hesitate to contact us if you are interested in our products.
