20foot Prefabricated steel frame house construction details
Hot Sale Easy to Install Detachable modular Insulated Container MOQ:1 set.
item no.:
950lead time:
7-15 daysproduct orgin:
Chinashipping port:
Xiamen / Qingdao / Tianjin,Chinapayment:
T/T; LC at sightcolor:
Customized
Insulated sandwich panel features
☆ Metal panels with glass wool core material is A1 fireproof grade;
☆ Excellent sound-absorbing performance;
☆ Classic roof panel type,easy installation way;
☆ Resistance to moisture and good thermal insulation;
☆ High ribs make roof system drainage better.
Sandwich panel ceiling use
This fireproof glass wool sandwich panel is mainly used in steel structure buildings,such as steel processing plants, large equipment plants, energy plants, etc.
Steel ceiling panels specifications
|
Product name |
50mm fiberglass sandwich panel roof |
Remark |
|
Effective width |
950 mm |
|
|
Panel thickness |
50 mm |
Other thickness for roof: |
|
|
|
75, 100, 150, 200 mm |
|
Surface sheets |
PPGI/ PPGL/ Aluminum sheets/ Al-Mg-Mn alloy metal sheets/ Stainless steel/ PVC sheet |
|
|
Steel thickness |
0.35 - 0.70 mm |
|
|
Aluminum sheets/ Al-Mg-Mn alloy metal sheets |
0.70 - 1.20 mm |
|
|
Stainless steel |
0.40 - 0.60 mm |
|
|
Core material density |
48 - 68 KG/M³ |
|
|
Regular panel color |
White grey, Sea blue, Sliver grey, Dk grey, Iron grey |
Color could be customized too. |
|
Coating type choice |
PE/ PVDF/ HDP/ SMP, etc. |
|
|
Available length |
20FT container: ≤ 5.95m |
|
Sandwich panel ceiling board production process
☆ Hydraulic uncoiler;
☆ Film mulching & panel cutting;
☆ Forming equipment;
☆ Preheating equipment;
☆ Fully automatic cotton renewal device;
☆ Automatic cutting machine;
☆ Packing & Stacking.
Metal sandwich panel roof rendering
Packing & Delivery:
☆ Packing:
Seaworthy packing standards:
PVC on both sides to protect the roof panel surfaces;
Packed with kraft paper to protect the panel ends;
Put EPS foam on the each space to keep the panels from squeezing each other.
If you have special requirement,please feel free to discuss with us.This is to make us improved,and protect your goods well.
☆ Delivery:
Delivery time for regular colors,coating types and thickness: 7-10 days ;
Delivery time for special colors,coating types and thickness: 15-25 days ;
Delivery term: FOB/CIF/CFR/DDP is available;
We can find good forwarder for customer or accept appointed forwarder from customers.
