50mm corrugated EPS composite sandwich roof panels

The EPS sandwich roof panels with performance of waterproof, heat&sound insulation, lightweight and favorable price.MOQ:500M²/Color & Size
  • item no.:

    950
  • lead time:

    7-15 days
  • product orgin:

    China
  • shipping port:

    Xiamen / Qingdao / Tianjin,China
  • payment:

    T/T; LC at sight
  • color:

    Customized
  • product details

Characteristics

EPS sandwich panel with performance of light weight, shearing resistant, corrosion resistance, high durability, weather fastness, etc.;

☆ Compared with other sandwich panel, EPS sandwich panel has a favorable price;

☆ Also EPS sandwich board has excellent insulation performance: hear insulation, sound insulation, waterproof performance, etc.

☆ It is easy to install, reduce a mount of construction cost

☆ Various protective coatings can be chosen: PE, PVDF, HDP, SMP, they can extend service life.


Application

☆ Agricultural buildings: Pig, hen, cow houses,barns,etc;

☆ Industrial buildings: Steel structure factories,warehouses,steel sheds,etc;

☆ Cooling buildings: Food industry,vegatables strorage room,etc;

☆ Commericial buildings: Shop/store roofing,etc.


Specifications


Product name

50mm EPS foam insulation roof boards

Remark

Effective width

950 mm



Panel thickness

50 mm

Other thickness for roof:





 75, 100, 150, 200, 250 mm

Surface sheets

PPGI/ PPGL/ Aluminum sheets/ Al-Mg-Mn alloy metal sheets/ Stainless steel/ PVC sheet



Steel thickness

0.40 - 0.70 mm



 Aluminum sheets/ Al-Mg-Mn alloy metal sheets

0.70 - 1.20 mm



Stainless steel

0.40 - 0.60 mm



Core material density

8 - 20 KG/M³



Regular panel color

White grey, Sea blue, Sliver grey, Dk grey, Iron grey

Color could be customized too.

Coating type choice

PE/ PVDF/  HDP/ SMP, etc.



Available length

20FT container:  ≤ 5.95m
40FT container: ≤ 11.95m



Technical data

☆ Panel properties:

Panel Properties

Panel thicknessmm

50

75

100

150

200

Mass(kg/m²)

10.58

10.94

11.3

11.98

12.65

Thermal performance at 8

"R" Value(m²K/W)

1.6

2.3

2.9

4.2

5.5

Thermal performance at 20

"R" Value(m²K/W)

1.6

2.2

2.8

4.1

5.3



☆ Panel span table:

Multi-span, wind pressure acting outwards

Span (mm)

Panel Thickness (mm)



50

75

100

150

200

1500

4.15

5.90

7.61

7.74

7.75

2700

2.07

2.91

1.00

4.35

4.35

3900

1.17

1.72

2.41

3.04

3.05

5100

-

1.11

1.58

2.35

2.36

6300

-

-

1.10

1.77

1.93

7500

-

-

-

1.31

1.64

8700

-

-

-

-

1.43



Renderings

buy structural metal roof panels

metal sandwich panel roof for sales

insulated metal roof panels cost


Packing & Delivery:

☆ Packing:

Seaworthy packing standards:

PVC on both sides to protect the roof panel surfaces;

Packed with kraft paper to protect the panel ends;

Put EPS foam on the each space to keep the panels from squeezing each other.

If you have special requirement,please feel free to discuss with us.This is to make us improved,and protect your goods well.


☆ Delivery:

Delivery time for regular colors,coating types and thickness: 7-10 days ;

Delivery time for special colors,coating types and thickness: 15-25 day;

Delivery term: FOB/CIF/CFR/DDP is available;

We can find good forwarder for customer or accept appointed forwarder from customers.
