Solar photovoltaic roof sandwich panels are specially designed for photovoltaic roofs. It can also be used as plain/common sandwich roofing panels.
Ridges can be attached directly to the buckles without penetrating the roof structure.
The roof panels are made of high-quality color-coated panels.
After continuous cold bending, high flame retardant and thermal insulation polyurethane liquid is injected in the middle, and it is processed by high pressure, heating, foaming, curing and other processes,
and then compounded with the surface material. The product quality is stable and can be cut to any size.
Specification :
Product Name |
PV PUR/PIR sandwich roof panel |
PV Rock wool roof sandwich panel |
PV Glasswool sandwich roof panel |
Model |
PV-PU/PIR 950R |
PV-RW 950R |
PV-GW 950R |
Effective width |
950mm/1000mm |
||
Thickness |
50/75/100/120/150/175/200mm |
||
Specification |
Corrugated height 40mm; Peak spacing 316mm/333mm |
||
Joint type |
Hidden screw connection |
||
Surface profile |
Flat, embossed, square wave, V wave |
||
Surface material |
Galvanized sheet; |
Advantages of photovoltaic solar roof panels:
1. The panels of this roof are connected by hidden nails, and the panel surfaces are closely lapped;
2. The excellent energy-saving and thermal insulation performance of polyurethane, combined with the utilization of solar clean energy, creates a pure green and environmentally friendly roof;
3.40mm peak height, multi-peak design, which greatly improves the load-bearing capacity of the roof and meets the load-bearing requirements of photovoltaic maintenance;
4. The buckle-type wave crest design, equipped with special fixtures, can realize the rapid installation of photovoltaic roof system components.
FAQ
Q Which port can you sopport? Which port can you support?
A Qingdao port or Tianjin port or any other China port you need. If provide destination port, CFR and CIF can be quoted for your reference.
Q What’s your MOQ ?
A Usually Min.1*20’GP Container, because our production line is full automatic, if the qty is small , the cost of starting the machine is very high, the sales price will rise .
Q What is your lead time?
Usually 10-15 days .
What terms of payment do you usually use?
T/T 30% deposit and 70% balance Before shipment. Payment terms are negotiable for large order.
Q Can you supply samples?
A Yes, we supply small sample free of charge , but the freight is collected . we also have big sample , it is also free of charge , in order to save freight , can ship together with container .
