150mm Metal Insulation Rockwool Sandwich Panel With Pu Egde For Wall

Polyurethane edged rock wool sandwich panel have significant effects on fire prevention, thermal insulation and sound absorption. MOQ:500㎡/color&size
  • item no.:

    1000
  • lead time:

    7-15 days
  • product orgin:

    China
  • shipping port:

    Xiamen/Qingdao/Tianjian
  • payment:

    T/T, LC at sight
  • color:

    Customized
  • product details

Advantage

– Fire resistance and soundproofing efficiency. One feature of mineral wools is their behaviour in fires. Selected panels manufactured by Balex Metal are EI 240-rated, meaning that both the sealing and the fire rating of the partition is maintained for 240 minutes. This is enough time for people to leave the building safely as well as minimising the potential losses resulting from the fire.

– Another important feature is to have a partition designed to prevent the transmission of excessive noise. The best panel versions feature good soundproofing capabilities, which in practice translates to a soundproofing effectiveness of up to 33 db.


Firepoof

Firepoof

Sound absorbtion

Sound absorbtion

Beautiful appearance

Beautiful appearance

Widely use

Widely use

Definition of pu sandwich panel

Polyurethane edged rock wool sandwich panel rigid foam is currently recognized as the best international building fire protection and insulation board. It has low thermal conductivity, good load resistance, high bending strength, no water absorption, no decay, no moth bites, good flame retardancy, and a wide temperature range.


Application

It used in various fire and sound insulation places, such as office partitions, dance halls, shopping malls, gymnasiums and other places, as well as sound insulation and drying rooms in studios and recording studios.


Specification

Product componentPU sealing rockwool sandwich panel for wall
Effective width1000mm
Available length20FT container: <5.95m
40FT container: < 11.95m
Rib height36mm
Rib distance300mm
Rib quantities4 ribs
Core thickness150mm
Other Core thickness50/75/100/200mm
Core material density38-42KG/M3 for PU;
 80-150KG/MJ for rockwool
Steel sheet thickness0.40-0.75mm
Stainless steel sheet thickness0.40-0.70mm
Al-Mg-Mn alloy metal sheet /Aluminum sheet thickness0.70-1.20mm
Surface sheetsPPGI/ PPGL/ Aluminum sheets/
Al-Mg-Mn alloy metal sheets
Coating choicePE/PVDF/HDP/SMPfect.
Panel colorAs RAL
Joint methodConcealed joint


Packing & Delivery:

A.Packing:

Seaworthy packing standards:

PVC on both sides to protect the panel ends;

Packed with paper to protect the panel ends;

Put EPS foam on the each space to keep the panel from squeezing each other.

If you have special requirement, please feel free to discuss with us. This is to make us improved, and protect your goods well.

B. Delivery:

Delivery time for regular colors,coating types and thickness: 7-10 days ;

Delivery time for special colors,coating types and thickness: 15-25 days ;

Delivery term: FOB/CIF/CFR/DDP is available;

We can find good forwarder for customer or accept appointed forwarder from customers.
